China machinery automatic core veneer composer for plywood production

Product Description

Specification

Models

CXCT-4C1

CXCT-4C2CXCT-4B1
Knife length1350(675 x 2 No.s)1350(675 x 2 No.s)1350(675 x 2 No.s)mm
Weight7T6T5T
After jointing size1,300x2600mm1300x2600mm1300x2600mm
Veneer thickness1.0-4.0mm1.0-4.0mm1.0-4.0mm
Feeding speed32(can be adjust) 6-7sheet (4*8ft)Max. m/Min32Max. m/Min32Max. m/Min
Number of glue threads5-7Rows7Rows7Rows
Number of hole detectors7Point13Point10Point
Total power required22KW21KW21KW
In- feed conveyor3KW3KW3KW

Separation device for waste

50*75 Air- operated50*75 Air- operated50*75  Air- operated
Conveying device for out-feeding3KW3KW3KW
Heater for glue melting for edge and yarn application5.5kw5.5kw5.5kw
Lifting table and stacking machine2.2kw2.2kw2.2kw

Dimension

12.5mx2.5mx2.3m12.5mx2.5mx2.3m12.5mx2.5mx2.3m

Output

6-7 sheet per minute6-7 sheet per minute5-6 sheet per minute
This machine is mainly used for the production of plywood, LVL, floor base material, furniture board, construction plywood, container flooring board, melamine plywood, blockboard and so on.

It can be used for the horizontal splicing of rotary cut core veneer with the thickness of 1.2-3.6mm.
It changes the traditional manual veneer forming technology and makes plywood paving unitized and automatic.

It saves lots of core finishing worker, improves the quality of products and saves labor costs.
Details Images
Servo Motor
Mitsubishi servo drive can protect veneer from over lap .
Intelligent thickness detecting
Detect core veneer thickness and cut uneven thickness part. Improve core veneer quality. Mechanical positioning is firm and accurate, no damage and non-contact measurement;
Famous brand electrical parts
Japan Mitsubishi PLC , Siemens brand inverter, Schneider band electrical parts.
Low voltage circuit breaker
Schneider low voltage circuit breaker .High precision of voltage stabilization, automatic protection when output short circuit, wide voltage range and strong anti-interference ability.
Festo Rotary Cylinder
Festo rotary cylinder control glue sticking position accuracy .That guarantee veneer no any overlap .
Machine frame laser cutting
The machine frame is made by laser cutting , stable and durable.
Clinet’s factory installat
